Pettit Odyssey 60 Ablative Bottom Paint

Pettit Odyssey 60 Multi-Season Ablative Boat Bottom Paint

Pettit Odyssey 60 is a high-copper, multi-season ablative bottom paint. This ablative paint delivers exceptional multi-season performance against fouling by offering the highest copper content available in an ablative paint. With significantly more copper than competitors, Odyssey 60 offers stronger protection at a better value. It provides protection in all water types and is compatible over most bottom paints.

Pettit Odyssey 60 features fast dry technology, providing quick turnaround and increased production for all applicators. Unique controlled erosion technology minimizes coating build-up while keeping underwater surfaces smooth. Its ablative surface wears away with use, providing a continuous supply of fresh biocides while eliminating the need for sanding. Odyssey 60 can be hauled and re-launched without repainting.

 Pettit Odyssey 60 provides excellent antifouling protection and is backed by the industry's strongest limited warranty. The Hull Defense 18 Month Limited Warranty offers peace of mind to every boater. Odyssey 60 offers the most dependable and trusted antifouling paint in the industry.

Features:

• Fast dry, VOC compliant standard for boatyards
• High-copper (65%) ablative protection in all waters
• Smooth polishing finish prevents buildup and sanding
• Compatible over most bottom paints
• Covered by HD (Hull Defense) 18 Month Limited Warranty

Specifications:

• Pack Size: 1 US Gallon
• Type: Copper-based ablative
• Recommended Usage: All fouling waters
• Colors Available: 1265 Blue, 1365 Green, 1665 Red, 1865 Black
• Number of Coats Recommended: 2 minimum
• Coverage: 440 ft2/gal
• VOC: 370 grams/liter
• Biocide: Cuprous Oxide 65%

Associated Products:

Pettit Protect Epoxy Primer - Primer for bare fiberglass applications

Pettit 120 Thinner - For surface prep

How Much Pettit Odyssey 60 Do I Need for My Boat?

Refer to the chart below to calculate how much Odyssey 60 paint you will need for your boat.

1. Calculate the square footage of the hull to be painted - multiply the length of the hull by the beam then multiply that total by .85
2. Divide that number (your square foot total) by the amount of coverage Odyssey 60 provides. (440 square foot per gallon). This will give you a one-coat total.

Example: If your boat has a length of 28', and a beam of 8.5', you will multiply 28 x 8.5 x .85 to get your total square footage. The total square footage for this boat is 202.3 square feet. A gallon of Odyssey 60 has a coverage of 440 square feet per gallon for one coat, so one gallon will be enough for two coats.

How to Apply Pettit Odyssey 60 Bottom Paint

Odyssey 60 is heavily loaded with cuprous oxide. As a result, there is a tendency for settling to occur, especially if the paint has been on the shelf for several months. It is necessary to thoroughly mix the paint before using. If possible, shake the can of paint on a mechanical paint shaker. Before using, check the sides and bottom of the can to make sure all the pigment has been mixed in. Adhere to all application instructions, precautions, conditions, and limitations to obtain optimum performance.

When spraying, do not thin Odyssey 60 more than 10% (12 ounces per gallon) or inadequate paint film thickness will occur. When applying by roller, use a short nap (3/8" maximum) roller cover.

• Application Methods: Brush, roller, airless or conventional spray
• Number of Coats: 2 minimum
• Dry Film Thickness: 2 mils (3.6 wet mils)
• Coverage: 440 sq. ft/gal.
• Application Temp: 50°F Min. / 90°F Max.
• Thinner: 120 Brushing Thinner

Application Systems

• Previously Painted Surfaces
• If previous coating is in good condition, thoroughly sand with 80 grit paper then solvent clean with 120 Brushing Thinner.
• Apply two finish coats of Odyssey 60.
• If previous coating is soft or in poor condition, remove to the bare surface by sanding or using EZ Speed Strip 125.
• Proceed with appropriate bare system.
• Bare Fiberglass
• All bare fiberglass, regardless of age, should be thoroughly cleaned with 92 Bio-Blue Hull Surface Prep or dewaxed several times with D-95 Dewaxer. Then proceed with one of the systems below:
• Sanding Method:
• Sand hull thoroughly with 80 grit sandpaper to a dull, frosty finish and rewash with 120 Brushing Thinner.
• Apply two or three thin coats of Odyssey 60.
• Non-Sanding Method:
• Thoroughly clean, dewax surface with 92 Bio-Blue Surface Prep using a course nylon scuff pad.
• Rinse all residue from surface and let dry.
• Apply one coat of Pettit Protect Epoxy Primer 4700/4701 following primer label instructions.
• Apply two or three thin coats of Odyssey 60.
• Barrier Coat
• Prepare the fiberglass surface as mentioned above (sanding method).
• Apply two - three coats of Pettit Protect Epoxy Primer per label instructions.
• Apply two or three thin coats of Odyssey 60.
• Bare Wood
• Sand thoroughly with 80 grit sandpaper and wipe clean.
• Apply a coat of 6627 Tie-Coat Primer thinned 25% with 97 Epoxy Thinner directly to bare wood.
• Allow drying for 4 hours then apply two un-thinned coats of Odyssey 60.
• Previously Painted Wood
• Thoroughly sand existing hard antifouling paint
• If priming is necessary on bare wood spots, apply a touch-up coat of 6627 Tie-Coat Primer thinned 25% with Epoxy thinner.
• Apply coats of Odyssey 60.
• Steel Hulls
• Clean surface to remove grease and dirt.
• Remove loose rust and scale from the metal surface by scraping or sandblasting.
• Blow off residue then apply one or two coats of Pettit 6980 Rustlok Primer.
• Follow with two coats of Pettit 4700/4701 Epoxy Primer.
• Follow with Odyssey 60.

Do not use Pettit Odyssey 60 on aluminum hulls and outdrives.

Click to Download Pettit Odyssey 60 Bottom Paint Application Instructions

Frequently Asked Questions

What is Pettit Odyssey 60 Multi-Season Ablative Boat Bottom Paint used for?

Pettit Odyssey 60 Multi-Season Ablative Boat Bottom Paint is a copper-based ablative antifouling paint designed to provide protection against fouling in all water types. Its controlled erosion technology allows the surface to wear away during use, helping minimize coating buildup and the need for sanding between applications.

How many coats of Pettit Odyssey 60 should I apply?

Apply a minimum of two coats of Pettit Odyssey 60. The product provides approximately 440 square feet of coverage per gallon per coat. Application requirements can vary by surface, so follow the appropriate system for fiberglass, wood, steel, or previously painted surfaces.

Can Pettit Odyssey 60 be used on aluminum hulls?

No. Pettit Odyssey 60 should not be used on aluminum hulls or outdrives. The product is specified for use in all fouling waters, but aluminum hulls and outdrives are specifically excluded from its approved applications.

What surfaces can Pettit Odyssey 60 be applied to?

Pettit Odyssey 60 can be applied as part of specified systems for fiberglass, wood, steel, and previously painted surfaces. The required preparation and primers vary by substrate. It is also compatible over most bottom paints when the existing coating is properly prepared and in suitable condition.

How should Pettit Odyssey 60 be prepared and applied?

Thoroughly mix Pettit Odyssey 60 before use because its high cuprous oxide content can settle during storage. It can be applied by brush, roller, airless spray, or conventional spray. When spraying, do not thin more than 10%, and when rolling, use a short-nap roller cover no larger than 3/8 inch.

What temperature range is recommended for applying Pettit Odyssey 60?

The recommended application temperature range for Pettit Odyssey 60 is 50°F to 90°F. At 70°F, the paint is dry to touch in approximately 30 minutes, can be recoated after 6 hours, and can be launched after 16 hours. Drying times vary with application temperature.
