Bennett 12" x 4" BOLT Electric Trim Tab Kit

Bennett BOLT124 12" x 4" BOLT Electric Trim Tab Kit

Bennett Marine has been leading the way in electric trim tabs since 1960 and is trusted by the leading boat builders for over half a century. Founded on the principles of quality and service Bennett electric trim tab systems are some of the best on the market today.

The Bennett Bolt trim tabs have been designed to outperform and outlast any other trim tab system on the market. The Bolt system uses states of the art technology and cutting-edge advances to manufacture a superior system. Common in outdated technology, the Bennett BOLT electric trim tab sets have developed technology that reduces water intrusion and common part malfunctions.

Bennett electric trim tab systems are designed for flatboats, center console, dual console, deck boats, bowriders, bass boats, and runabouts and are more suitable for single actuator use and for trailered boats 12 to 17 feet. When selecting the right size Bennett BOLT trim tab system, keep in mind the span is the side-to-side measurement and the chord is the fore-to-aft measurement.

NOTE: Bennett Electric Trim Tab sizes are in format span x chord. Span is the side to side measurement, chord is the fore to aft measurement.

Trim Tab Dimensions:

• Width: 12"
• Depth: 4"

Features:

• Wires are threaded through the upper hinge so no wires are exposed to the marine environment. This adds protection and safety.
• Water-tight black nylon actuator offers trouble-free operation.
• Main seal has been placed high to protect against marine growth and water intrusion failures.
• Runs quieter than competitors’ products.
• Installation is fast- the actuator does not require disassembly.
• Lifetime warranty for electric actuators
• Solidly constructed for a long service lifespan
• Bennett Part#: BOLT124
• Yamaha Part#: 6BT-50013-43-00

What's Included:

• (2) BEA2000 12-volt trim tab actuators
• (2) Stainless steel trim planes and mounting plates.
• (2) 20 ft harnesses with waterproof connectors.
• 6ft. wire harnesses and waterproof connectors.

SWITCH SOLD SEPARATELY

Click here to download Bennett BOLT124 12" x 4" BOLT Electric Trim Tab Kit Installation Instructions

Frequently Asked Questions

What is the Bennett BOLT124 12" x 4" BOLT Electric Trim Tab Kit designed for?

The Bennett BOLT124 electric trim tab kit is designed for boats such as flatboats, center consoles, dual consoles, deck boats, bowriders, bass boats, and runabouts. It is more suitable for single actuator use and trailered boats 12 to 17 feet long.

What are the trim tab dimensions of the Bennett BOLT124?

The Bennett BOLT124 features trim tabs measuring 12 inches wide by 4 inches deep. Bennett specifies trim tab sizes using span by chord, with span being the side-to-side measurement and chord being the fore-to-aft measurement.

What is included with the Bennett BOLT124 Electric Trim Tab Kit?

The Bennett BOLT124 kit includes two BEA2000 12-volt trim tab actuators, two stainless steel trim planes and mounting plates, two 20-foot harnesses with waterproof connectors, and 6-foot wire harnesses with waterproof connectors. The switch is sold separately.

How are the wires protected on the Bennett BOLT124 trim tabs?

The Bennett BOLT124 routes the wires through the upper hinge so they are not exposed to the marine environment. The kit also uses water-tight black nylon actuators, with the main seal positioned high to help protect against marine growth and water intrusion failures.

Are the Bennett BOLT124 actuators covered by a warranty?

Yes. The Bennett BOLT124 includes a lifetime warranty for its electric actuators. The trim tab system is also designed with solid construction for a long service lifespan.

Does the Bennett BOLT124 kit include a control switch?

No. The control switch is sold separately. The kit includes the two electric actuators, stainless steel trim planes and mounting plates, 20-foot harnesses with waterproof connectors, and 6-foot wire harnesses with waterproof connectors.
